This black-and-white movie from NASA's
Cassini mission shows a polar projection of the curious six-sided jet
stream at Saturn's north pole known as "the hexagon" in the infrared.
Image credit: NASA/JPL-Caltech/University of Arizona. Full image and caption - enlarge image
NASA's Cassini spacecraft has obtained the highest-resolution movie
yet of a unique six-sided jet stream, known as the hexagon, around
Saturn's north pole.
This is the first hexagon movie of its kind, using color filters, and the first to show a complete view of the top of Saturn down to about 70 degrees latitude. Spanning about 20,000 miles (30,000 kilometers) across, the hexagon is a wavy jet stream of 200-mile-per-hour winds (about 322 kilometers per hour) with a massive, rotating storm at the center. There is no weather feature exactly, consistently like this anywhere else in the solar system.
"The hexagon is just a current of air, and weather features out there that share similarities to this are notoriously turbulent and unstable," said Andrew Ingersoll, a Cassini imaging team member at the California Institute of Technology in Pasadena. "A hurricane on Earth typically lasts a week, but this has been here for decades -- and who knows -- maybe centuries."
Weather patterns on Earth are interrupted when they encounter friction from landforms or ice caps. Scientists suspect the stability of the hexagon has something to do with the lack of solid landforms on Saturn, which is essentially a giant ball of gas.
Better views of the hexagon are available now because the sun began to illuminate its interior in late 2012. Cassini captured images of the hexagon over a 10-hour time span with high-resolution cameras, giving scientists a good look at the motion of cloud structures within.
They saw the storm around the pole, as well as small vortices rotating in the opposite direction of the hexagon. Some of the vortices are swept along with the jet stream as if on a racetrack. The largest of these vortices spans about 2,200 miles (3,500 kilometers), or about twice the size of the largest hurricane recorded on Earth.
Scientists analyzed these images in false color, a rendering method that makes it easier to distinguish differences among the types of particles suspended in the atmosphere -- relatively small particles that make up haze -- inside and outside the hexagon.
"Inside the hexagon, there are fewer large haze particles and a concentration of small haze particles, while outside the hexagon, the opposite is true," said Kunio Sayanagi, a Cassini imaging team associate at Hampton University in Virginia. "The hexagonal jet stream is acting like a barrier, which results in something like Earth's Antarctic ozone hole."
The Antarctic ozone hole forms within a region enclosed by a jet stream with similarities to the hexagon. Wintertime conditions enable ozone-destroying chemical processes to occur, and the jet stream prevents a resupply of ozone from the outside. At Saturn, large aerosols cannot cross into the hexagonal jet stream from outside, and large aerosol particles are created when sunlight shines on the atmosphere. Only recently, with the start of Saturn's northern spring in August 2009, did sunlight begin bathing the planet's northern hemisphere.
"As we approach Saturn's summer solstice in 2017, lighting conditions over its north pole will improve, and we are excited to track the changes that occur both inside and outside the hexagon boundary," said Scott Edgington, Cassini deputy project scientist at NASA's Jet Propulsion Laboratory in Pasadena, Calif.
A black-and-white version of the imaging camera movie and movies obtained by Cassini's visual and infrared mapping spectrometer are also tools Cassini scientists can use to look at wind speeds and the mini-storms inside the jet stream.
Cassini launched in 1997 and arrived at Saturn on July 1, 2004. Its mission is scheduled to end in September 2017. The Cassini-Huygens mission is a cooperative project of NASA, the European Space Agency and the Italian Space Agency. JPL manages the mission for NASA's Science Mission Directorate in Washington. JPL designed, developed and assembled the Cassini orbiter and its two onboard cameras. The imaging team is based at the Space Science Institute, Boulder, Colo.
A Google+ Hangout to discuss these results and other Cassini images will take place today at 12:30 p.m. PST (3:30 p.m. EST): http://bit.ly/askcassini .
The event will be broadcast live on NASA Television and streamed on the agency's website. For information on NASA TV, visit: http://www.nasa.gov/ntv .
The event will also be streamed live on Ustream with a moderated chat available at: http://www.ustream.tv/nasajpl2 .
Questions can be asked on the Google Hangout event page, in the chat box on the Ustream site and via Twitter using the hashtag #askCassini.
More information about Cassini is available at: http://www.nasa.gov/cassini and http://saturn.jpl.nasa.gov .
