What's Baking on Titan?



NASA's Cassini spacecraft obtained this image of a feature shaped like a hot cross bun in the northern region of Titan (left) that bears a striking resemblance to a similar feature on Venus (right). Image Credit: NASA/JPL-Caltech/ASI . Full image and caption -  View unlabeled image

This image from NASA's Cassini spacecraft shows an ancient southern sea that used to sprawl out near the south pole of Saturn's moon Titan. Image Credit: NASA/JPL-Caltech/ASI/Proxemy Research.

Full image and caption - View unlabeled image - enlarge image



These images obtained by NASA's Cassini spacecraft show Titan's stable northern lake district. Image Credit: NASA/JPL-Caltech/ASI .  Full image and caption  -  enlarge image

Radar images from NASA's Cassini spacecraft reveal some new curiosities on the surface of Saturn's mysterious moon Titan, including a nearly circular feature that resembles a giant hot cross bun and shorelines of ancient seas. The results were presented today at the American Astronomical Society's Division of Planetary Sciences conference in Reno, Nev.

Steam from baking often causes the top of bread to lift and crack. Scientists think some similar process involving heat may be at play on Titan. The image showing the bun-like mound was obtained on May 22, 2012, by Cassini's radar instrument. Scientists have seen similar terrain on Venus, where a dome-shaped region about 20 miles (30 kilometers) across has been seen at the summit of a large volcano called Kunapipi Mons. They theorize that the Titan cross, which is about 40 miles (70 kilometers) long, is also the result of fractures caused by uplift from below, possibly the result of rising magma.

"The 'hot cross bun' is a type of feature we have not seen before on Titan, showing that Titan keeps surprising us even after eight years of observations from Cassini," said Rosaly Lopes, a Cassini radar team scientist based at NASA's Jet Propulsion Laboratory, Pasadena, Calif. "The 'bun' may be the result of what is known on Earth as a laccolith, an intrusion formed by magma pushing up from below. The Henry Mountains of Utah are well-known examples of this geologic phenomenon."

Another group of Cassini scientists, led by Ellen Stofan, who is based at Proxemy Research, Rectortown, Va., has been scrutinizing radar images of Titan's southern hemisphere. Titan is the only place other than Earth that has stable liquid on its surface, though the liquids on Titan are hydrocarbon rather than water. So far, vast seas have only been seen in Titan's northern hemisphere.

A new analysis of Cassini images collected from 2008 to 2011 suggests there were once vast, shallow seas at Titan's south pole as well. Stofan and colleagues have found two good candidates for dry or mostly dry seas. One of these dry seas appears to be about 300 by 170 miles (475 by 280 kilometers) across, and perhaps a few hundred feet (meters) deep. Ontario Lacus, the largest current lake in the south, sits inside of the dry shorelines, like a shrunken version of a once-mighty sea.

Scientists led by Oded Aharonson, another radar team member based at the California Institute of Technology in Pasadena, think that cycles analogous to Earth's Croll-Milankovich cycles, which explain climate changes in terms of the way Earth orbits around the sun, are at play on Titan, too. Such cycles on Titan would cause long-term transfer of liquid hydrocarbons from pole to pole. By this model, the south pole could have been covered with extensive seas less than 50,000 years ago.

"The seas on Titan are temporary hosts for experiments in prebiotic chemistry, and we know they are cycling from one hemisphere to the other over 100,000 years," said Stofan. "I'd love to get a closer look at the seas of the north or these dry seabeds to examine the extent to which this prebiotic chemistry has developed."

The Cassini team has confirmed some of the stability of Titan's northern seas by looking at radar images from Cassini taken about one Titan season (in this case, six Earth years) apart. The newer images, from May 22, 2012, on the same flyby as the hot cross bun images, show the shorelines stayed about the same, indicating the northern lakes are not transient weather events, in contrast to the temporary darkening of parts of the equator after a rainstorm in 2010.

The Cassini-Huygens mission is a cooperative project of NASA, the European Space Agency and ASI, the Italian Space Agency. NASA's Jet Propulsion Laboratory, a division of the California Institute of Technology in Pasadena, manages the mission for NASA's Science Mission Directorate, Washington. The Cassini orbiter was designed, developed and assembled at JPL. The RADAR instrument was built by JPL and the Italian Space Agency, working with team members from the US and several European countries. JPL is a division of the California Institute of Technology in Pasadena.

Jia-Rui C. Cook 818-354-0850
Jet Propulsion Laboratory, Pasadena, Calif.
jia-rui.c.cook@jpl.nasa.gov
